Roof Rail Edge Protection System

EasyDeck – Your Trusted Edge Protection for Roof Work

Roof Rail Edge Protection System

EasyDeck – Your Trusted Edge Protection for Roof Work

The EasyDeck Edge Protection system from SafeSmart Access is a superior and versatile safety solution designed to provide optimal fall protection for workers on construction sites. Constructed from a lightweight aluminium material, the system is both durable and easily transportable, ideal for rapid installation and teardown processes which a dynamic building site demands.

This innovative edge protection system is a freestanding unit, circumventing the need for any building fixings. This feature not only speeds up the setup process, requiring only two individuals, but it also maintains the integrity of the building’s facade. The EasyDeck Edge Protection uniquely combines the EasyRail edge protection system with SafeSmart Access’s prefabricated platforms and cantilever support brackets to ensure reliability and worker safety.

Standard SafeSmart aluminium scaffold components such as guardrails and platforms are utilised within the system, allowing those already in possession of SafeSmart products to save costs by adding to the systems they already have. For increased versatility, the system is capable of using certified aluminium or wooden planks to create a robust work platform that meets a variety of project needs.

Height-adjustable screw jacks enable the system to adapt to the uneven terrain often found on construction sites, while the adjustable platform heights along the EasyRail post ensure workers have the flexibility and the optimum level of safety, regardless of the task at hand.

Safety and Efficiency

The EasyDeck Edge Protection system not only improves safety on site but also enhances efficiency. Its simple and rapid assembly reduces time spent in setup, allowing workers to focus on the task at hand without concern for their safety. This high degree of efficiency is combined with uncompromised compliance with the AS/NZS 4994.1:2009 safety standards, ensuring the highest levels of edge protection are met.

Usage Scenarios

  • Construction Sites: Seamlessly provides fall protection around the perimeters of new buildings under construction.
  • Refurbishment Projects: Can be quickly repositioned around existing structures for facade renovations or maintenance.
  • Uneven Terrains: Offers stable and secure edge protection on slopes or irregular ground conditions.
  • Multi-structure Setups: Modular in nature, it can be used in various configurations to fit around corners and join end to end.

SafeSmart Access’s EasyDeck Edge Protection system is the ideal solution for construction and maintenance companies requiring dependable, quick-to-install safety systems that comply with established industry standards

  • A high strength, lightweight welded aluminium structure
  • Protect from roof falls while working on the soffit and wall of the building
  • Free-standing system - does not require any fixing in
  • Fast, two person set up
  • Unique combination of the EasyRail roof rail edge protection system, SafeSmart Access prefabricated platforms and cantilever support brackets
  • The system incorporates standard SafeSmart aluminium scaffold components, such as guardrails,and platforms, save money by adding to the system you already have
  • Certified aluminium or wooden planks can also be,used to create a work platform
  • Height adjustable screw jacks allow for uneven ground
  • Platform height is adjustable along the length of the EasyRail post
  • Can also be put on wheels and utilised in modules, provide access roof rail edge protection when working on structures such as portable buildings
SKU: 210237-ER
90 Degree Fixed Coupler
Used for attaching horizontal rails to the posts.
SKU: 290703-ER
Aluminium EasyRail Tube
Can be cut to specific lengths. Used for toerail, midrail and handrails. Up to 6m span between posts.
SKU: 210420
Base Frame
Supports the roof post using two internal joining spigots.
SKU: 210423
Diagonal Brace
Must be used every 4 bays minimum.
SKU: 210079
Handrail Post
Attaches to the inner sleeve on the platform support bracket greater than 225mm away from the wall.
SKU: HS036
Hatch Platform
Ladder protrudes through the hatch lid for use when the ladder access is within the platform. 3.0m.
SKU: HS046-ER
Internal Joining Spigot
Used for joining tubes together end-to-end by expanding inside them.
SKU: HS035-ER
Outriggers
Connect to roof posts and provide extra stability to the system. Must be used every 3 bays minimum.
SKU: 210422
Platform Support Bracket
Attaches to the roof post and supports the work platform.
SKU: 210078
Proscaf Swing Gate
Used where the ladder access is outside the platform.
SKU: 210081 & 210082
Reinforced Grasper Ledger
Used to span across corners. 2 sizes available.
SKU: HS037
Snaplock Guardrail
Used to connect the base frames together longitudinally. Can also be used as a guardrail. 3.0m.

The EasyDeck Edge Protection system from SafeSmart Access is a superior and versatile safety solution designed to provide optimal fall protection for workers on construction sites. Constructed from a lightweight aluminium material, the system is both durable and easily transportable, ideal for rapid installation and teardown processes which a dynamic building site demands.

This innovative edge protection system is a freestanding unit, circumventing the need for any building fixings. This feature not only speeds up the setup process, requiring only two individuals, but it also maintains the integrity of the building’s facade. The EasyDeck Edge Protection uniquely combines the EasyRail edge protection system with SafeSmart Access’s prefabricated platforms and cantilever support brackets to ensure reliability and worker safety.

Standard SafeSmart aluminium scaffold components such as guardrails and platforms are utilised within the system, allowing those already in possession of SafeSmart products to save costs by adding to the systems they already have. For increased versatility, the system is capable of using certified aluminium or wooden planks to create a robust work platform that meets a variety of project needs.

Height-adjustable screw jacks enable the system to adapt to the uneven terrain often found on construction sites, while the adjustable platform heights along the EasyRail post ensure workers have the flexibility and the optimum level of safety, regardless of the task at hand.

Safety and Efficiency

The EasyDeck Edge Protection system not only improves safety on site but also enhances efficiency. Its simple and rapid assembly reduces time spent in setup, allowing workers to focus on the task at hand without concern for their safety. This high degree of efficiency is combined with uncompromised compliance with the AS/NZS 4994.1:2009 safety standards, ensuring the highest levels of edge protection are met.

Usage Scenarios

  • Construction Sites: Seamlessly provides fall protection around the perimeters of new buildings under construction.
  • Refurbishment Projects: Can be quickly repositioned around existing structures for facade renovations or maintenance.
  • Uneven Terrains: Offers stable and secure edge protection on slopes or irregular ground conditions.
  • Multi-structure Setups: Modular in nature, it can be used in various configurations to fit around corners and join end to end.

SafeSmart Access’s EasyDeck Edge Protection system is the ideal solution for construction and maintenance companies requiring dependable, quick-to-install safety systems that comply with established industry standards
